Description
• UHF operation.
• Stereo or MixMode™ control for custom monitor mixes.
• 32 user-selectable frequencies per system.
• Up to 16 compatible frequencies for 16 different mixes.
• Frequency compatible with all Shure Wireless systems
(country dependent).
• MPX Stereo audio transmission.
• Switchable high-frequency boost on P7R.
• +4 dBu and –10 dBV input level select switch on P7T.
• Electronically balanced, combined 1/4-in. and XLR
connectors on P7T can be used with balanced or unbalanced
outputs.
• Volume and Balance dials on the P7R Receiver.
• Internal linear power supply on P7T, switchable between
120 VAC and 230 VAC.
• Peak transmitter modulation limiter with fixed threshold and
modulation limit indicators.
• Loop out connectors on P7T for multiple mix setups and easy
installation.
• Tone-Key squelch.
• Half-rack chassis on P7T complete with mounting hardware.
• All metal construction on P7T and P7R.
• Headphone monitor on P7T for local listening.
• Earphones reduce ambient sound levels by sealing off the
